The Sentiacu LSM series represents the latest generation of 2D LiDAR products, highlighted by high performance, excellent reliability, and cost-effectiveness. It is well-suited for service robotics scenarios such as industrial sensing, and robots including food delivery, hotel delivery, and commercial cleaning.
Suitable for SLAM navigation and point cloud obstacle avoidance on challenging surfaces like black floors, glass, stainless steel, and marble tiles.
Utilizes unique target enhancement technology, enabling a range of 20 meters even on targets with 10% reflectivity.
Features settable weak signal threshold strength adjustment to adapt to different usage scenarios.
Incorporates a built-in multi-level filtering algorithm; customers can configure settings as needed to address tailing problems.
A fixed 0.225° angular resolution and horizontal plane error of ±0.5° ensure consistent horizontal scanning distance accuracy.
A maximum point cloud density of 40k points per second, providing data including azimuth, distance, and reflection intensity.
A simplified, minimalist mechanical design, dedicated temperature drift error elimination, and professional EMC design ensure proven reliability across different application scenarios.
The LiDAR has passed 50 rigorous reliability tests involving different light intensities, temperatures, humidity levels, reflectivity, dust, fog, and water, maintaining superior performance throughout.
LSM40 | LSM25 | LSM15 | |
Range | ≥40m(70%Reflectivity) ≥20m(10%Reflectivity) | ≥25m(70%Reflectivity) ≥10m(10%Reflectivity) | ≥40m(70%Reflectivity) ≥20m(10%Reflectivity) |
Horizontal FOV | 270° | 270° | 270° |
Point Rate | 43.2KHZ | 43.2KHz | 18KHz(10Hz) 14.4kHz(20Hz) |
Horizontal Resolition | 0.1°0.25° | 0.1°0.25° | 0.2°0.5° |
Scan Frenquency | 10Hz 20Hz 25Hz 30Hz | 10Hz 20Hz 25Hz 30Hz | 10Hz 20Hz |
Accuracy | +2cm | +2cm | +2cm |
